LG SIGNAGE 86UH5J 86" LFD

• PANEL

• Screen Size
• 86
• Panel Technology
• IPS
• Back Light Type
• Edge
• Aspect Ratio
• 16 : 9
• Native Resolution
• 3840 x 2160 (UHD)
• Refresh Rate
• 120Hz
• Brightness
• 500nit (Typ.)
• Contrast Ratio
• 1,100:1
• Dynamic CR
• 1,000,000:1
• Color gamut
• NTSC 72%
• Viewing Angle(H x V)
• 178 X 178
• Color Depth
• 10bib, 1.07Billion colors
• Response Time
• 8ms (G to G)
• Surface Treatment(Haze)
• 28%
• Life time
• 50,000Hrs (Typ.)
• Operation Hours (Hours/Day)
• 24/7
• Portrait / Landscape
• Yes / Yes

• CONNECTIVITY

• Input
• HDMI (3, HDMI1/HDMI2 : HDCP 2.2/1.4, HDMI3 : HDCP 1.4), DP (1, HDCP2.2/1.3), DVI-D (HDCP1.4), Audio In, RS232C IN (1, 4pin Phone-jack), RJ45(LAN), IR IN, USB2.0 Type A(1)
• Output
• HDMI Out, Audio Out, RS232C OUT (1, 4pin Phone-jack)

• MECHANICAL SPECIFICATION

• Bezel Color
• Black
• Bezel Width
• Even bezel : 14.3mm
• Weight(Head)
• 49.0Kg
• Packed Weight
• 72.5Kg (With Pallet)
• Monitor Dimension(W x H x D)
• 1926.2 x 1097.2 x 60.6mm (without Handle and LG Logo)
• Carton Dimensions(W x H x D) (Box outer size)
• 2073 x 1250 x 285mm
• Handle
• Yes
• VESA Standard Mount Interface
• 600 x 400

• KEY FEATURE

• Key features
• Internal Memory 16 GB, Built-in Wi-Fi, Temperature Sensor, Auto Brightness sensor, Acceleration(Gyro) Sensor, Local Key Operation, webOS6.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Multi-screen (PIP, PBP (4)), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected), Power (Smart Energy Saving, PM mode, Wake on LAN,Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom

• ENVIRONMENT CONDITIONS

• Operation Temperature
• 0 °C to 40 °C
• Operation Humidity
• 10 % to 80 %

• POWER

• Power Supply
• AC 100-240V~, 50/60Hz
• Power Type
• Built-In Power

• POWER CONSUMPTION

• Typ.
• 215W (TBD)
• Max.
• 280W (TBD)
• BTU (British Thermal Unit)
• 733.69 BTU/Hr(Typ.), 955.5 BTU/Hr(Max) (TBD)
• Smart Enegy Saving(~70%)
• 150.5W (TBD)
• DPM
• 0.5W
• Power off
• 0.5W

• SOUND

• Speaker
• Yes

• CERTIFICATION

• Safety
• CB / NRTL
• EMC
• FCC Class "A" / CE / KC
• ErP / Energy Star
• Yes (NewErP) / No (TBD)

• OPS COMPATIBILITY

• OPS Type Compatible
• Yes

• SOFTWARE COMPATIBILITY

• SuperSign CMS
• Yes
• SuperSign Control / Control+
• Yes / Yes
• SuperSign WB
• Yes
• SuperSign Media Editor
• Yes
• Mobile CMS
• Yes
• Signage 365 Care
• Yes

• LANGUAGE

• OSD
• English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish, Arabic

• ACCESSORY

• Basic
• Remote Controller(include battery 2ea)
• Power Cord
• QSG
• Regulation Book
• Phone to RS232C Gender
