APC BK500 0.5 KVA SZÜNETMENTES TÁPEGYSÉG NEMA OUTLETS

• Main

• Run time for load 300 W
• Min-max: 30-300 W
• 3min 24s
• Max. Capacity Used
• 100 %
• Main Input Voltage
• 120 V
• Main Output Voltage
• 120 V
• rated power in W
• 300 W
• Rated power in VA
• 500 VA
• Input Connection Type
• NEMA 5-15P
• output connection type
• 3 NEMA 5-15R
• 3 NEMA 5-15R surge
• Cable length
• 6 ft (1.83 m)
• Number of cables
• 1
• Battery Type
• Lead-Acid battery
• Provided equipment
• CD with software
• Cord management straps
• User Manual
• USB cable

• General

• Number of power module free slots
• 0
• Number of power module filled slots
• 0
• Redundant
• No

• Physical

• color
• Beige
• Height
• 6.50 in (16.5 cm)
• Width
• 3.58 in (9.1 cm)
• Depth
• 11.18 in (28.4 cm)
• Net Weight
• 13.82 lb(US) (6.27 kg)
• Mounting Location
• Front
• Mounting preference
• No preference
• Mounting Mode
• Not rack-mountable
• Two post mountable
• 0
• USB compatible
• Yes

• Input

• Input Frequency
• 50/60 Hz +/- 3 Hz auto-sensing
• Efficiency at full load
• 98...140 V

• Output

• Max Configurable Power (Watts)
• 300 W
• Output Frequency (sync to mains)
• 50/60 Hz +/- 3 Hz sync to mains
• Topology
• Standby
• Waveform Type
• Stepped approximation to a sinewave
• Maximum output current
• 10 A
• Maximum configurable power in VA
• 500 VA
• Transfer Time
• 8ms typical : 12ms maximum

• Environmental

• Ambient Air Temperature for Operation
• 32.104 °F (0.40 °C)
• Relative Humidity
• 0.95 %
• Operating altitude
• 0...10000 ft
• Ambient Air Temperature for Storage
• 5.113 °F (-15.45 °C)
• Storage Relative Humidity
• 0.95 %
• Storage altitude
• 0.50000 ft (0.00.15240.00 m)
• Acoustic level
• 45 dBA
• heat dissipation
• 24 Btu/h

• Batteries & Runtime

• Included Battery Modules
• 0
• Battery Slots Empty
• 0
• Typical recharge time
• 8 h
• RBC Quantity
• 1
• Battery Voltage
• 12 V
• Battery Capacity
• 7.0 Ah
• Battery Charge Power (Watts)
• 10 W rated
• Battery power in VAH
• 106 VAh capacity
• 78 VAh runtime
• Battery Life
• 4.6 year(s)
• Replacement battery
• RBC2
• Battery graph comments
• This graph is based on actual measured runtime data. All measurements were taken with new, fully charged batteries and a balanced resistive load (PF = 1.0). Actual runtimes may vary from the values of this graph. Actual runtimes are dependent on several variables including battery age, battery charge level, environmental conditions and characteristics of the connected load.
• Extendable Run Time
• 0

• Communications & Management

• Control panel
• LED status display with on line : on battery : replace battery and overload indicators
• Alarm
• Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

• Surge Protection and Filtering

• Surge energy rating
• 480 J
• Filtering
• Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : mee
• Let Through Voltage Rating
• 300 V

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 2 év gyártó által biztosított szervizgarancia
