MIKROTIK CAPGI-5HAXD2HAXD CAP AX 802.11AX DUAL BAND 2XRJ45 GBE LAN WIFI6 ACCESS POINT

• Specifications

• Architecture
• ARM 64bit
• CPU
• IPQ-6010
• CPU core count
• 4
• CPU nominal frequency
• auto (864 - 1800) MHz
• Switch chip model
• IPQ-6010
• RouterOS license
• 4
• Operating System
• RouterOS v7
• Size of RAM
• 1 GB
• Storage size
• 128 MB
• Storage type
• NAND
• MTBF
• Approximately 200'000 hours at 25C
• Tested ambient temperature
• -40°C to 70°C
• IPsec hardware acceleration
• Yes

• Wireless capabilities

• Wireless 2.4 GHz Max data rate
• 574 Mbit/s
• Wireless 2.4 GHz number of chains
• 2
• Wireless 2.4 GHz standards
• 802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz
• 6
• Wireless 2.4 GHz chip model
• QCN-5022
• Wireless 2.4 GHz generation
• Wi-Fi 6
• Wireless 5 GHz Max data rate
• 1200 Mbit/s
• Wireless 5 GHz number of chains
• 2
• Wireless 5 GHz standards
• 802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz
• 5.5
• Wireless 5 GHz chip model
• QCN-5052
• Wireless 5 GHz generation
• Wi-Fi 6
• WiFi speed
• AX1800

• Ethernet

• 10/100/1000 Ethernet ports
• 2
• Number of 1G Ethernet ports with PoE-out
• 1

• Powering

• Number of DC inputs
• 2 (DC jack, PoE-IN)
• DC jack input Voltage
• 18-57 V
• Max power consumption
• 40 W
• Max power consumption without attachments
• 11 W
• Cooling type
• Passive
• PoE in
• 802.3af/at
• PoE in input Voltage
• 18-57 V

• PoE-out

• PoE-out ports
• Ether2
• PoE out
• Passive PoE up to 57V
• Max out per port output (input 18-30 V)
• 600 mA
• Max out per port output (input 30-57 V)
• 400 mA
• Max total out (A)
• 600 mA
• Total output current
• 0.4
• Total output power
• 19.2

• Certification & Approvals

• Certification
• CE, FCC, IC, EAC, ROHS
• IP
• 20

• Other

• CPU temperature monitor
• Yes
• Mode button
• Yes
