TP-LINK CPE605 150MBPS KÜLTÉRI WIRELESS ACCESS POINT

• HARDWARE FEATURES

• Processor
• Qualcomm 560MHz CPU, MIPS 74Kc
• Memory
• 64MB DDR2 RAM,8MB Flash
• Interface
• 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
• 1 Reset Button
• Power Supply
• Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
• Voltage range: 16-27VDC
• Dimensions ( W x D x H )
• 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
• Antenna Gain
• 23dBi
• Antenna Beamwidth
• 7°(Azimuth), 10°(Elevation)
• Protection
• 15KV ESD Protection
• 6KV Lightning Protection
• Enclosure
• Material: Outdoor PC stabilized plastic
• Weatherproof: IP65 water and dust proof design

• WIRELESS FEATURES

• Wireless Standards
• IEEE 802.11a/n
• Proprietary Protocol
• TDMA Mode (with Pharos MAXtream enabled)
• Wireless Speeds
• Up to 150Mbps (40MHz,Dynamic)
• Up to 72.2Mbps (20MHz,Dynamic)
• Up to 36.1Mbps (10MHz,Dynamic)
• Up to 18.05Mbps (5MHz,Dynamic)
• Frequency
• 5.15~5.85GHz
• Transmit Power
• Max. 23dBm (Adjustable power by 1dBm)

• SOFTWARE FEATURES

• IPv6
• Yes
• Network Configuration
• WAN: Static/Dynamic/PPPoE/L2TP/PPTP
• LAN: Static/Dynamic/DHCP
• Forwarding: ALG/UPnP/Virtual Server/Port Trigger
• Security: SPI Firewall/ Ping Forbidden/DoS Protection
• Access Control
• Static Routing
• Bandwidth Control
• IP & MAC Binding
• Wireless Configurations
• Pharos MAXtream TDMA Technology
• Selectable Channel Width: 5/10/20/40MHz
• Auto Channel Selection
• Transmit Power Control
• Dynamic Frequency Selection(DFS)
• WDS Enable/Disable
• Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
• 64/128/152-bit WEP Encryption
• SSID Broadcast Enable/Disable
• Multi-SSID with VLAN Tagging(AP Mode only)
• Distance/ACK Timeout Setting
• Wireless MAC Address Filter
• Wireless Advanced:
• Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
• Management
• Discovery and Remote Management via Pharos Control application
• HTTP/HTTPS Web-based management
• System log
• SNMP Agent(v2c)
• Ping Watch Dog
• Dynamic DDNS
• SSH Server
• System Tools
• Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
• Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
• Spectrum Analyzer
• Speed Test
• Ping
• Traceroute
• System-level Optimizations
• Optimized IGMP Snooping/Proxy for multicast applications
• Hardware watch dog

• POE ADAPTER FEATURES

• Dimensions(W x D x H)
• 85.8×43.9×29.7 mm
• Interfaces
• 1 AC Jack with Earth Ground
• 1 10/100Mbps Shielded Ethernet Port (Power + Data)
• 1 10/100Mbps Shielded Ethernet Port (Data)
• Button
• Remote Reset Button
• Power Status LEDs
• Green
• Input
• 100-240VAC, 50/60Hz
• Output
• 24VDC, 0.6A Max
• +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
• Efficiency
• >84.29%

• OTHERS

• Package Contents
• Outdoor Wireless CPE
• 24V 0.5A Passive PoE Adapter
• Pole Mounting Straps
• AC Power Cord
• Installation Guide
• System Requirements
• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
• Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
• Environment
• Operating Temperature: -40°C~70°C (-40°F~158°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~95% non-condensing
