EZVIZ EP7 SMART HOME VIDEO KAPUTELEFON, VEZETÉK NÉLKÜLI, NAPELEM, 2K, 7 HÜVELYK KIJELZŐ, TÁVOLI NYITÁS, 512GB

• Specifications

• Model
• CS-EP7

• Outdoor Doorbell

• Camera

• Image Sensor
• 1/2.7" Progressive Scan CMOS (Supports low light sensitivity)
• Lens
• 2.0 mm @ F2.2,viewing angle: 162° (Diagonal)
• Day & Night
• IR-cut filter with auto-switching, 850 nm infrared light × 2 (max. 6m)
• Max. Resolution
• 2K, 2048 × 1296
• DNR
• 2D / 3D DNR
• Video Compression
• H.265 / H.264
• Frame Rate
• Max: 15fps; Self-Adaptive during network transmission

• Connection and Function

• Open the door (Gate)
• Support 2 wiring ports. 1-10m distance. The intercom panel provides a dry-contact connection, without an electric current, to connect to the button for automated gate, gate breaking capacity: 12V / 2A
• Unlock (Electric strike plate)
• Support 2 wiring ports. 1-10m distance. The electric strike plate or lock that you order must have a mechanical memory; the power supply to the electric strike plate or lock must not exceed 12V / 0.8A, otherwise should do as user manual.
• Door Open Methods
• 1.RFID badge unlock (CPU card × 3 pcs) 2.Password unlock 3.App remote unlock 4.Indoor display unlock

• Outdoor Doorbell Interface

• Audio Input
• Built-in high-sensitivity microphone
• Audio Output
• Built-in high-power speaker
• Doorbell Button
• Supports 1 button.
• Name Card
• Supports handwritten. 3 cards stickers included (1 sticker already on the intercom panel).
• Terminal
• Two wiring ports to connect gate. Two wiring ports to connect electric strike plate. Two wiring ports to connect the solar panel.
• Password Keypad
• 0-9 10-digial password keyboard; support 5 sets of 6-10 digital passwords; press the keypad to turn on the light, the light can be turn off

• Network

• Wi-Fi Standard
• IEEE 802.11 AH
• Frequency Range
• 904 M - 928 M (US), 865 M-867 M (EU)
• Channel Bandwidth
• 8 M (U ), 2 M (EU)
• Security
• 64 / 128 bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
• Wi-Fi HaLow Pairing
• AP pairing
• Max Transmission Distance for Intercom and monitor
• Up to 350m in open area; up to 80m in two enclosed walls

• General

• Operation Conditions
• -20°C to 60°C , Humidity 95% or less (non-condensing)
• IP Grade
• Waterproof IP65, with shield cover
• Power Supply
• Battery (7.3V), EZVIZ Doorbell Solar Panel
• Battery Capacity
• 2600 mAh 7.3V (5200mAh 3.7V) rechargeable and detachable lithium battery 85 days at the rate of using 3 minutes per day, and open the electric strike plate 10 times
• Product Dimension
• 175 × 86 × 34 mm

• Interior Display

• Display size
• 7" touch screen
• Resolution
• 1024 × 600

• Interface

• Audio Input
• Built-in high-sensitivity microphone
• Audio Output
• Built-in high-power speaker
• Button
• Screen On / Off Button
• Terminal
• Two wiring ports to connect the power
• Storage
• Supports microSD card (Up to 512 GB)

• Network Parameters

• Interface Protocol
• EZVIZ Cloud Proprietary Protocol
• Protocol
• EZVIZ Cloud Proprietary Protocol

• Wi-Fi Parameters

• Wi-Fi Standard
• IEEE802.11b, 802.11g, 802.11n, 802.11ac
• Frequency Range
• 2.4G: 2.4 GHz ~ 2.4835 GHz 5G: 5.15 GHz ~ 5.25 GHz
• Channel Bandwidth
• Supports 20MHz
• Security
• 64 / 128-bit WEP,WPA / WPA2, WPA-PSK / WPA2-PSK
• Transmission Rate
• 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps, 11ac: 433.3Mbps

• Function

• Multiple ringtones
• Up to 20 ringtones
• Functions
• Live view, playback, two-way talk, video call

• General

• Operation Conditions
• -10°C to 45°C, humidity 95% or less (non-condensing)
• Size
• 180 × 111 × 15 mm
• Power Supply
• 12-24VDC 1A power supply, adaptor (12V 1A included in package)
• Power Consumption
• 8W, Max. 24W

• Solar Panel

• Performance Parameter

• Power Voltage
• 8.1V max
• Max. Power Current
• 240mA
• Max. Power
• 1.2W
• Operating Temperature
• -20°C to 50°C
• Product Dimension
• 126 × 59 × 44mm
• IP Grade
• IP65

• General

• Net Weight in Total
• 675g
• Weight with Package
• 1865g

• In the box

• In the box
• Monitor
• Wall Bracket for Monitor
• Power Adapter for Monitor
• Intercom Panel (Doorbell) with a Weather-proof Shield
• Drill Template for Monitor
• Drill Template for Intercom Panel
• Screwdriver
• Name Card (×3)
• Badges (×3)
• Screw Kit (×2)
• Pin (×1)
• Wires and Wire Connectors
• Battery for Intercome Panel (× 1)
• USB Cable for Battery (× 1)
• Power Supply Jack Connector Cable (× 1)
• Solar Panel (× 1)
• Regulatory Information (×2)
• Quick Start Guide

• Certifications

• Certifications
• CE / REACH / WEEE / RoHS

Garancia fogyasztók részére

• 2 év kötelező jótállás (gyártó által biztosított szervizgarancia)

Garancia nem fogyasztók részére

• 2 év gyártó által biztosított szervizgarancia
