TP-LINK EAP230-WALL DUAL BAND AC1200 FALRA RÖGZÍTHETŐ WIRELESS ACCESS POINT

• HARDWARE FEATURES

• Interface
• Uplink: 1× 10/100/1000 Mbps Ethernet Port
• Downlink: 1× 10/100/1000 Mbps Ethernet Port
• Physical Security Lock
• No
• Button
• LED/Wi-Fi Button, RESET
• Power Supply
• 802.3af/802.3at PoE
• Power Consumption
• 7 W
• Dimensions
• 3.4 × 3.4 × 1.2 in (86.8 × 86.8 × 30.2 mm)
• Antenna
• 2 Dual-Band Antennas
• 2.4 GHz: 2× 4 dBi
• 5 GHz: 2× 3.6 dBi
• Mounting
• Wall Plate Mounting
• Hardware Watch Dog
• Yes

• WIRELESS FEATURES

• Wireless Standards
• IEEE 802.11n/g/b/ac
• Frequency
• 2.4 GHz and 5 GHz
• Signal Rate
• 5 GHz: Up to 867 Mbps
• 2.4 GHz: Up to 300 Mbps
• Wireless Functions
• 16 SSIDs (Up to 8 SSIDs on each band)
• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control (Adjust Transmit Power on dBm)
• QoS(WMM)
• Load Balance
• Rate Limit
• Reboot Schedule
• Wireless Schedule
• Wireless Statistics based on SSID/AP/Client
• MU-MIMO
• Band Steering
• Beamforming
• Wireless Security
• Captive Portal Authentication
• Access Control
• Wireless Mac Address Filtering
• Wireless Isolation Between Clients
• SSID to VLAN Mapping
• Local LAN port based VLAN
• Rogue AP Detection
• 802.1X Support
• 64/128/152-bit WEP / WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
• Transmission Power
• CE:
• <20 dBm (2.4 GHz, EIRP)
• <23 dBm (5 GHz, EIRP)

• MANAGEMENT

• Omada App
• Yes
• Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Cloud Access
• Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
• Email Alerts
• Yes
• LED ON/OFF Control
• Yes
• Management MAC Access Control
• Yes
• SNMP
• v1,v2c
• System Logging Local/Remote Syslog
• Local/Remote Syslog
• SSH
• Yes
• Web-based Management
• HTTP/HTTPS
• L3 Management
• Yes
• Multi-site Management
• Yes
• Management VLAN
• Yes

• OTHERS

• Package Contents
• Omada AC1200 Wireless MU-MIMO Gigabit Wall-Plate Access Point EAP230-Wall
• Installation Guide
• Mounting Screw
• System Requirements
• Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
• Environment
• Operating Temperature: 0-40 °C (32-104 °F)
• Storage Temperature: -40-70 °C (-40-158 °F)
• Operating Humidity: 10-90% RH non-condensing
• Storage Humidity: 5-90% RH non-condensing

Garancia fogyasztók részére

• 2 év kötelező jótállás + 3 év gyártó által biztosított szervizgarancia

Garancia nem fogyasztók részére

• 5 év gyártó által biztosított szervizgarancia
