TP-LINK ER707-M2 VEZETÉKES VPN ROUTER 1XWAN(2.5G) +1XWAN/LAN(2.5G) +1XSFP + 4XLAN(1000MBPS) + 1XUSB

• HARDWARE FEATURES

• Standards and Protocols
• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
• Interface
• 1× 2.5G RJ45 WAN Port
• 1× 2.5G RJ45 WAN/LAN Port
• 1× Gigabit SFP WAN/LAN Port
• 4× Gigabit RJ45 WAN/LAN Ports
• 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)
• Network Media
• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100? STP (Max 100 m)
• 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100? STP (Max 100 m)
• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
• 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
• Fan Quantity
• Fanless
• Button
• Reset Button
• Power Supply
• 12V/1.5A Adapter
• PoE Budget
• -
• Flash
• 128MB NAND
• DRAM
• 1 GB DDR4
• LED
• PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
• Dimensions ( W x D x H )
• 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
• Protection
• 4 kV surge protection
• Enclosure
• Steel
• Mounting
• Desktop/Wall Mounting
• Max Power Consumption
• 14.2 W (with USB2.0 connected)
• 7.1 W (without USB2.0 connected)

• PERFORMANCE

• Concurrent Session
• 500,000
• New Sessions /Second
• 4,200
• NAT (Static IP)
• 2364.45 Mbps / 2343.28 Mbps
• NAT(DHCP)
• 2364.24 Mbps / 2326.21 Mbps
• NAT(PPPoE)
• 2350.93 Mbps / 2125.83 Mbps
• NAT (L2TP)
• 1249.04 Mbps / 831.12 Mbps
• NAT (PPTP)
• 1169.23 Mbps / 1175.52 Mbps
• IPsec VPN Throughput
• ESP-MD5-AES256: 537.12 Mbps
• ESP-SHA1-AES256: 754.65 Mbps
• L2TP VPN Throughput
• Unencrypted: 1442.65 Mbps
• Encrypted: 346.43 Mbps
• SSL VPN Throughput
• 142.99 Mbps
• 66 Byte Packet forwarding rate
• 1832.69 Mbps / 1741.84 Mbps
• 1,518 Byte Packet forwarding rate
• 2461.18 Mbps / 2457.32 Mbps

• BASIC FUNCTIONS

• WAN Connection Type
• IPv4_Static IP
• IPv4_Dynamic IP
• IPv4_PPPOE
• IPv4_L2TP
• IPv4_PPTP
• IPv6_PPP
• IPv6_DHCPv6
• IPv6_Static IP
• IPv6_6in4
• IPv6_Pass-Through
• Mobile Broadband: 4G/3G modem for backup via USB port
• MAC Clone
• Modify WAN/LAN MAC Address
• DHCP
• DHCP Server/Client
• DHCP Address Reservation
• Multi-IP Interfaces
• Multi-Net DHCP
• IPv6
• WAN Connection
• VLAN
• 802.1Q VLAN
• IPTV
• IGMP v2/v3 Proxy

• ADVANCED FUNCTIONS

• Advanced Routing
• Static Routing
• Policy Routing
• Bandwidth Control
• IP/Port-based Bandwidth Control
• Guarantee & Limited Bandwidth
• Load Balance
• Intelligent Load Balance
• Application Optimized Routing
• Link Backup (Timing§, Failover)
• Online Detection
• NAT
• One-to-One NAT
• Multi-Net NAT
• Virtual Server
• Port Triggering
• NAT-DMZ
• FTP/H.323/SIP/IPSec/PPTP ALG
• UPnP
• Security
• Attack Defense:
• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN
• Filtering
• Web Group Filtering
• URL Filtering
• Web Security
• ARP Inspection:
• Sending GARP Packets
• ARP Scanning
• IP-MAC Binding
• Access Control
• Source/Destination IP Based Access Control
• Session Limit
• IP-based Session Limit

• VPN

• IPsec VPN
• 100 IPSec VPN Tunnels
• LAN-to-LAN, Client-to-LAN
• Main, Aggressive Negotiation Mode
• DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm
• IKEv1/v2
• MD5, SHA1 Authentication Algorithm
• NAT Traversal (NAT-T)
• Dead Peer Detection (DPD)
• Perfect Forward Secrecy (PFS)
• PPTP VPN
• PPTP VPN Server
• PPTP VPN Clients (12)
• 60 Tunnels (Shared with L2TP)
• PPTP with MPPE Encryption
• L2TP VPN
• L2TP VPN Server
• L2TP VPN Clients (12)
• 60 Tunnels (Shared with PPTP)
• L2TP over IPSec
• OpenVPN
• OpenVPN Server
• OpenVPN Clients (6)
• 66 OpenVPN Tunnels

• SECURITY

• Filtering
• WEB Group Filtering
• URL Filtering
• Web Security
• ARP Inspection
• Sending GARP Packets
• ARP Scanning
• IP-MAC Binding
• Attack Defense
• TCP/UDP/ICMP Flood Defense
• Block TCP Scan (Stealth FIN/Xmas/Null)
• Block Ping from WAN
• Access Control
• Source/Destination IP Based Access Control

• AUTHENTICATION

• Web Authentication
• No Authentication
• Simple Password
• Hotspot (Local User/Voucher /SMS/Radius)
• External Radius Sever
• External Portal Sever
• Facebook

• MANAGEMENT

• Omada App
• Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
• Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller
• Cloud Access
• Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.
• Service
• Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
• Maintenance
• Web Management Interface
• Remote Management
• Export & Import Configuration
• SNMP v1/v2c/v3
• Diagnostics (Ping & Traceroute)
• NTP Synchronize
• Syslog Support
• Zero-Touch Provisioning
• Yes. Requiring the use of Omada Cloud-Based Controller.
• Management Features
• Automatic Device Discovery
• Intelligent Network Monitoring
• Abnormal Event Warnings
• Unified Configuration
• Reboot Schedule
• Captive Portal Configuration
• ZTP (Zero-Touch Provisioning)

• OTHERS

• Certification
• CE, FCC, RoHS
• Package Contents
• ER707-M2
• Power Adapter
• Quick Installation Guide
• System Requirements
• Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
• Environment
• Operating Temperature: 0-40 ? (32-104 ?);
• Storage Temperature: -40-70 ? (-40-158 ?)
• Operating Humidity: 10-90% RH non-condensing
• Storage Humidity: 5-90% non-condensing
