DAHUA NVR1104HS-W NVR RÖGZÍTŐ (4 CSATORNA, H265, 1080P@25FPS, HDMI, VGA, USB, 1X SATA (MAX 16TB), 1X RJ45)

• System

• Main Processor
• Industrial-grade embedded processor
• Operating System
• Embedded Linux
• Operating Interface
• Web; Local GUI

• Audio and Video

• Access Channel
• 4 channels
• Network Bandwidth
• Wired mode: 40 Mbps incoming, 40 Mbps recording and 20 Mbps outgoing
• Wireless mode: 16 Mbps incoming, 16 Mbps recording
• Resolution
• 6 MP; 5 MP; 4 MP; 3 MP; 2 MP; 720p; D1
• Decoding Capability
• 1-channel 6 MP@25 fps; 1-channel 5 MP@25 fps; 2-channel 4 MP@25 fps; 2-channel 3 MP@25 fps; 4-channel 1080p@25 fps
• Video Output
• 1 × VGA, 1 × HDMI (simultaneous)
• Multi-screen Display
• 1, 4 views
• Third-party Camera Access
• Onvif

• Compression Standard

• Video Compression
• Smart H.265; H.265; Smart H.264; H.264; MJPEG
• Audio Compression
• PCM; G711A; G711U; G726

• Network

• Network Protocol
• HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; Alarm Server;P2P
• Mobile Phone Access
• Android; iOS
• Interoperability
• ONVIF (profile T/S/G); CGI; SDK
• Browser
• Chrome; IE 9 or later; Firefox

• Recording Playback

• Multi-channel Playback
• Up to 4 channels
• Record Mode
• Manual record; alarm record; motion detection record; schedule record
• Storage Method
• Local HDD and network
• Backup Method
• USB device
• Playback Mode
• Instant playback, general playback, event playback, tag playback, smart playback (motion detection)

• Alarm

• General Alarm
• Motion detection; privacy masking; video loss; PIR alarm
• Anomaly Alarm
• Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception
• Alarm Linkage
• Recording; snapshot; buzzer; log; preset; tour

• Port

• Audio Input
• 1
• Audio Output
• 1
• HDD Interface
• 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature
• USB
• 1 front USB 2.0 port, 1 rear USB 2.0 port
• HDMI
• 1
• VGA
• 1
• Network Port
• 1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port

• General

• Power Supply
• 12 VDC, 1.5 A
• Power Consumption
• Total output of NVR is ? 10 W (without HDD)
• Net Weight
• 0.824 kg (1.82 lb)
• Gross Weight
• 1.56 kg (3.44 lb)
• Product Dimensions
• 260.3 mm × 247.3 mm × 44.7 mm (10.25" × 9.74" × 1.76") (W × L × H)
• Packaging Dimensions
• 372 mm × 117 mm × 308 mm (14.65" × 4.61" × 12.13") (W × L × H)
• Operating Temperature
• -10 °C to + 45 °C (+ 14 °F to +113 °F)
• Operating Humidity
• 10%-93% (RH)
• Installation
• Rack or desktop
