DAHUA NVR2108HS-8P NVR RÖGZÍTŐ (8 CSATORNA,H265,80MBPS RÖGZÍTÉSI SÁVSZÉLESSÉG,HDMI+VGA,2XUSB,1X SATA, 8XPOE)

• System

• Main Processor
• Industrial-grade embedded processor
• Operating System
• Embedded Linux
• Operating Interface
• Web; Local GUI

• AI

• AI by Camera
• Perimeter protection; SMD Plus

• Perimeter Protection

• Perimeter Performance of AI by Camera (Number of Channels)
• 4

• SMD Plus

• SMD Plus by Camera
• 4-channel SMD Plus (AI by camera), secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change

• Audio and Video

• Access Channel
• 8 channels
• Network Bandwidth
• Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps
• Resolution
• 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1
• Decoding Capability
• 1-channel 12MP@30 fps; 1-channel 8MP@30 fps; 2-channel 5MP@30 fps; 3-channel 4MP@30 fps; 6-channel 1080p@30 fps
• Video Output
• 1 × VGA, 1 × HDMI (simultaneous)
• Multi-screen Display
• 1, 4, 8, 9 views
• Third-party Camera Access
• Onvif

• Compression Standard

• Video Compression
• Smart H.265; H.265; Smart H.264; H.264
• Audio Compression
• PCM; G711A; G711U; G726

• Network

• Network Protocol
• HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P
• Mobile Phone Access
• Android; iOS
• Interoperability
• ONVIF (profile T/S/G); CGI; SDK
• Browser
• Chrome; IE 9 or later; Firefox

• Recording Playback

• Multi-channel Playback
• Up to 8 channels
• Record Mode
• Manual record; alarm record; motion detection record; schedule record
• Storage Method
• Local HDD and network
• Backup Method
• USB device
• Playback Function
• 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
• 2. Full screen; backup (video clip/file); partially zom in; audio on/off

• Alarm

• General Alarm
• Motion detection; privacy masking; video loss; PIR alarm
• Anomaly Alarm
• Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception
• Intelligent Alarm
• Perimeter protection; SMD Plus
• Alarm Linkage
• Recording; snapshot; buzzer; log; preset; email; tour

• Port

• Audio Input
• 1
• Audio Output
• 1
• HDD Interface
• 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature
• USB
• 1 front USB 2.0 port, 1 rear USB 2.0 port
• HDMI
• 1
• VGA
• 1
• Network Port
• 1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port
• PoE Port
• 8 × PoE ports, 10/100 Mbps

• General

• Power Supply
• 48/53 VDC, 2/1.8 A
• Power Consumption
• Total output of NVR is ? 10 W (without HDD)
• Total output power of PoE is 72 W, the maximum output power of asingle port is 25.5 W
• Net Weight
• 0.89 kg (1.95 lb)
• Gross Weight
• 1.94 kg (4.28 lb)
• Product Dimensions
• 260 mm × 232.7 mm × 47.6 mm (10.24" × 9.16" × 1.87") (W × L × H)
• Packaging Dimensions
• 117 mm × 373 mm × 307 mm (4.61" × 14.69" × 12.09") (W × L × H)
• Operating Temperature
• -10 °C to +55 °C (14 °F to +131 °F)
• Operating Humidity
• 10%-93% (RH)
• Installation
• Rack or desktop
• Certifications
• CE: EN62368-1; EN55032; EN55024; EN55035; EN61000-3-2; EN61000-3-3; EN50130-4
• FCC: Part 15 Subpart B
