DAHUA NVR608H-32-XI NVR RÖGZÍTŐ (32 CSATORNA, H265, 640MBPS RÖGZÍTÉS, HDMI+VGA, 2XRJ45, 4XUSB, 8X SATA,ESATA,I/O,RAID)

• System

• Main Processor
• Industrial-grade processor
• Operating System
• Embedded Linux
• Operating Interface
• Web, Local GUI

• AI

• AI by Recorder
• Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus
• AI by Camera
• Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; object monitoring
• AcuPick AI by Camera + Recorder
• Max. 32-channel, 1 combined event per channel

• Perimeter Protection

• Perimeter Performance AI by Recorder (Number of Channels)
• Simultaneous mode: 32 channels, 10 IVS rules for each channel
• Heterogeneous mode: 24 channels, 10 IVS rules for each channel
• Refer to the information on video output for details on the mode
• Perimeter Performance of AI by Camera (Number of Channels)
• All channels (64 targets/s)

• Face Detection

• Face Attributes
• Gender; age group; glasses; expressions; face mask; beard
• Face Detection Performance of AI by Recorder (Number of Channels)
• Simultaneous mode: 8 channels (up to 12 face images/s each channel)
• Heterogeneous mode: 5 channels (up to 12 face images/s each channel)
• Refer to the information on video output for details on the mode
• Face Detection Performance of AI by Camera (Number of Channels)
• 32 channels

• Face Recognition

• Face Database Capacity
• Up to 40 face databases with 300,000 images, with a total capacity of 48 G.
• Face Recognition Performance of AI by Recorder (Number of Channels)
• Simultaneous mode: 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s; 8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s
• Heterogeneous mode: 16-channel FD (by camera) + FR (by recorder),image stream: 16 face images/s; 5-channel FD (by recorder) + FR (by recorder), video stream: 10 face images/s
• Refer to the information on video output for details on the mode
• Face Recognition Performance of AI by Camera (Number of Channels)
• 32 channels

• SMD Plus

• SMD Plus by Recorder
• 32-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
• SMD Plus by Camera
• All channels (128 targets/s)

• Video Metadata

• Metadata Performance of AI by Recorder (Number of Channels)
• 8 channels
• Metadata Performance of AI by Camera (Number of Channels)
• 32 channels
• People Attributes
• 9 human body attributes
• Human Attributes
• Top color, top type, hat, bag, age, gender and umbrella
• Motor Vehicle Attributes
• License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling,
• Non-motor Vehicle Attributes
• Vehicle model, vehicle color, number of persons, helmet.

• Vehicle License Plate Comparison

• ANPR by Camera (Number of Channels)
• All channels (64 targets/s)
• License Plate Database Capacity
• Blocklist and allowlist: 20,000

• Audio and Video

• Access Channel
• 32 channels
• Network Bandwidth
• AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing
• AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing
• Resolution
• 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF
• Decoding Capability
• AI disabled: 2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 11-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps;128-channel D1@30 fps
• AI enabled: 1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 5-channel 6 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps; 80-channel D1@30 fps
• Video Output
• 2 VGA, 4 HDMI; VGA: 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; HDMI4: 1920 × 1080, 1280 × 1024, 1280 × 720
• Simultaneous mode (simultaneously outputs video sources for all the HDMI1-4 and VGA1-2 ports)
• Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1 and HDMI2 is 4K; max. resolution of HDMI3 is 8K; max. resolution of HDMI4 is 1080p
• Heterogeneous mode (simultaneously outputs video sources for the VGA1 and HDMI1, or VGA2 and HDMI2. It also outputs heterogeneous video sources for HDMI1-4)
• Max. resolution of VGA1 and VGA2 is 1080p; max. resolution of HDMI1, HDMI2 and HDMI3 is 4K; max. resolution of HDMI4 is 1080p
• Multi-screen Display
• Main screen: 1/4/8/9/16/25/36
• Sub screen: 1/4/8/9/16/25/36
• Third-party Camera Access
• ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha

• Compression Standard

• Video Compression
• Smart H.265+; H.265; Smart H.264+; H.264; MPEG4; MJPEG
• Audio Compression
• G.711a; G.711u; PCM; G726

• Network

• Network Protocol
• HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI
• Mobile Phone Access
• iOS; Android
• Interoperability
• ONVIF (Profile S/profile T/Profile G); CGI; SDK
• Browser
• Chrome
• IE 9 or later
• Firefox
• Network Mode
• Multi-address mode, load balance, fault tolerance and other network port binding modes

• Recording Playback

• Multi-channel Playback
• Up to 16 channels
• Record Mode
• Manual; alarm; motion detection; scheduled
• Backup Method
• Portable hard drive, eSATA disk, burner, USB device and network
• Playback Mode
• 1. Play, pause, stop, fast forward, fast backward, rewind, play by frame
• 2. Full screen, backup (cut/file), partially enlarge, audio on/off

• Storage

• Disk Group
• Yes
• RAID
• RAID 0/1/5/6/10
• Hot Swapping
• Yes

• Alarm

• General Alarm
• Motion detection; video tampering; video loss; scene changing, PIR alarm, IPC external alarm
• Anomaly Alarm
• Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; abnormal behavior of fan
• Intelligent Alarm
• Face detection; face recognition; perimeter protection (intrusion and tripwire); SMD Plus alarms; ANPR; people counting; stereo analysis; crowd distribution; heat map
• Alarm Linkage
• Record; snapshot; IPC external alarm output; buzzer; log, preset; email

• Port

• Audio Input
• 1-channel RCA
• Audio Output
• 2-channel RCA
• Alarm Input
• 16 channels
• Alarm Output
• 8 channels
• Disk Interface
• 8 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
• eSATA
• 1
• RS-232
• 1
• RS-485
• 1 × A/B
• USB
• 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports)
• HDMI
• 4
• VGA
• 2
• Network Port
• 2 (10/100/1000/2500 Mbps Ethernet port, RJ-45)

• General

• Power Supply
• 100-240 VAC, 50/60 Hz
• Power Consumption
• <18 W (without HDD)
• Net Weight
• 6.40 kg (14.11 lb) (without HDD)
• Gross Weight
• 10.35 kg (22.82 lb) (without HDD)
• Product Dimensions
• 444.0 mm × 456.6 mm x 95.0 mm (17.48" × 17.98" × 3.74") (W × D × H)
• Packaging Dimensions
• 570.0 mm × 570.0 mm × 226.0 mm (22.44" × 22.44" × 8.90")(W × D × H)
• Operating Temperature
• -10 °C to +55 °C (14 °F to +131 °F)
• Storage Temperature
• 0 °C to +40 °C (+32 °F to +104 °F)
• Operating Humidity
• 10%-93% (RH), non-condensing
• Installation
• Rack or desktop
• Certifications
• FCC: 47 CFR FCC Part15, SubpartB, Class A
• CE-EMC: EN 55032:2020, Class A; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2020; EN 50130-4:2011+A1:2014
• CE-LVD: EN 62368-1:2014+A11:2017
