APC SMX3000RMHV2U 3000 VA 4U MAGASSÁGÚ SZÜNETMENTES TÁPEGYSÉG

• Main

• Run time for load
• 2700 W
• Min-max: 270-2700 W
• 6min 15s
• Max. Capacity Used
• 100 %
• Main Input Voltage
• 208 V
• 230 V
• Other Input Voltage
• 220 V
• 240 V
• Main Output Voltage
• 230 V
• Other Output Voltage
• 208 V
• 220 V
• 240 V
• rated power in W
• 2700 W
• Rated power in VA
• 3000 VA
• Input Connection Type
• IEC 320 C20
• Schuko CEE 7 / EU1-16P
• BS1363A British
• output connection type
• 8 IEC 320 C13
• 2 IEC Jumpers
• 1 IEC 320 C19
• Number of rack unit
• 2U
• Cable length
• 6 ft (1.83 m)
• Number of cables
• 1
• Battery Type
• Lead-Acid battery
• Provided equipment
• CD with software
• Documentation CD
• Smart UPS signalling RS-232 cable
• User Manual
• USB cable
• Rack Mounting brackets

• Batteries & Runtime

• Extendable Run Time
• 1
• Included Battery Modules
• 0
• Battery Slots Empty
• 0
• Typical recharge time
• 3 h
• RBC Quantity
• 1
• Battery Life
• 3.5 year(s)
• Replacement battery
• APCRBC117
• Battery power in VAH
• 738 VAh runtime
• Battery Charge Power (Watts)
• 245 W rated
• Battery option
• SMX120RMBP2U 1 2214 VAh
• SMX120RMBP2U 2 3690 VAh
• SMX120RMBP2U 3 5166 VAh
• SMX120RMBP2U 4 6642 VAh
• SMX120RMBP2U 6 9594 VAh
• SMX120RMBP2U 8 12546 VAh
• SMX120RMBP2U 10 15498 VAh

• General

• Number of power module
• 2400
• Number of power module filled slots
• 0
• Number of power module free slots
• 0
• product web sub-family
• Extended run
• Redundant
• No

• Physical

• color
• Black
• Height
• 3.35 in (8.5 cm)
• Width
• 17.01 in (43.2 cm)
• Depth
• 26.26 in (66.7 cm)
• Net Weight
• 82.28 lb(US) (37.32 kg)
• Mounting Location
• Front
• Mounting preference
• Lower
• Mounting Mode
• Rack-mounted
• Two post mountable
• 0
• USB compatible
• Yes

• Input

• Efficiency at full load
• 140...280 V
• Input Frequency
• 50/60 Hz +/- 3 Hz auto-sensing

• Output

• Crest factor
• 3 : 1
• Harmonic distortion
• Less than 5%
• Maximum configurable power in VA
• 3000 VA
• Max Configurable Power (Watts)
• 2700 W
• Transfer Time
• 2-4 ms
• 6ms typical : 10ms maximum
• Topology
• Line Interactive
• Waveform Type
• Sine wave
• Output Frequency (sync to mains)
• 50/60 Hz +/- 3 Hz sync to mains

• Environmental

• Acoustic level
• 55 dBA
• heat dissipation
• 184 Btu/h
• Operating altitude
• 0...10000 ft
• Ambient Air Temperature for Operation
• 32.104 °F (0.40 °C)
• Ambient Air Temperature for Storage
• 5.113 °F (-15.45 °C)
• Storage altitude
• 0.50000 ft (0.00.15240.00 m)
• Relative Humidity
• 0.95 %
• Storage Relative Humidity
• 0.95 %

• Communications & Management

• control panel
• Multi-function LCD status and control console
• Emergency Power Off (EPO)
• Yes
• Free slots
• 1
• Control panel
• LED status display with on line : on battery : replace battery and overload indicators
• Alarm
• Alarm when on battery : distinctive low battery alarm : configurable delays

• Surge Protection and Filtering

• Surge energy rating
• 645 J
• Filtering
• Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m
