TP-LINK TL-WA1201 DUAL BAND AC1200 ASZTALI WIRELESS ACCESS POINT

• HARDWARE FEATURES

• Interface
• 1× 10/100/1000 Mbps Ethernet Port (Supports Passive PoE)
• Button
• Power On/Off Button, WPS Button, Reset Button
• External Power Supply
• 12V/1.5A
• Wireless Standards
• IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz
• Dimensions ( W x D x H )
• 225×145.5×37 in (400×255×72 mm)
• Antenna Type
• 4 Fixed High Performance Antennas

• WIRELESS FEATURES

• Frequency
• 2.4 GHz and 5 GHz
• Signal Rate
• 867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz
• Reception Sensitivity
• 5 GHz:
• 11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm
• 11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm
• 11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm
• 11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm
• 2.4 GHz:
• 11g 54Mbps: -78 dBm
• 11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm
• 11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm
• Transmit Power
• CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz)
• FCC: <30dBm(2.4GHz&5GHz)
• Wireless Modes
• Access Point, Range Extender, Client, Multi-SSID
• Wireless Functions
• Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Wireless Multicast Forwarding, DHCP Server, Access Control
• Wireless Security
• 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions
• DHCP
• Server, DHCP Client List
• Quality of Service
• WMM
• Advanced Functions
• Captive Portal

• OTHERS

• Package Contents
• Wireless Access Point TL-WA1201
• Power Adapter
• RJ45 Ethernet Cable
• Quick Installation Guide
• PoE Power Injector
• System Requirements
• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1,
• 10, MAC OS, NetWare, UNIX or Linux
• Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
• Java-enabled browser
• Environment
• Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
• Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
• Protocol Support
• IPv4, IPv6
