QNAP NAS 6 FIÓKOS TS-673A-8G AMD RYZEN V1500B 4X2.2 GHZ, 8GB RAM, 2X2.5GBE, 4XUSB3.2

• TS-673A-8G

• CPU
• AMD Ryzen Embedded V1500B 4-core/8-thread 2.2 GHz processor
• CPU Architecture
• 64-bit x86
• Floating Point Unit
• Yes
• Encryption Engine
• Yes (AES-NI)
• System Memory
• 8 GB SODIMM DDR4 (1 x 8 GB)
• Maximum Memory
• 64 GB (2 x 32 GB)
• Memory Slot
• 2 x SODIMM DDR4
• Support ECC memory
• Flash Memory
• 5GB (Dual boot OS protection)
• Drive Bay
• 6 x 3.5-inch SATA 6Gb/s, 3Gb/s
• Drive Compatibility
• 3.5-inch SATA hard disk drives
• 2.5-inch SATA solid state drives
• Hot-swappable
• Yes
• M.2 Slot
• 2 x M.2 2280 PCIe Gen3 x1 slots
• SSD Cache Acceleration Support
• Yes
• GPU pass-through
• Yes
• 2.5 Gigabit Ethernet Port (2.5G/1G/100M)
• 2(2.5G/1G/100M)
• Wake on LAN (WOL)
• Yes
• Jumbo Frame
• Yes
• PCIe Slot
• 2
• Slot 1: PCIe Gen 3 x4
• Slot 2: PCIe Gen 3 x4
• USB 3.2 Gen 2 (10Gbps) Port
• 3 x Type-A USB 3.2 Gen 2 10Gbps
• 1 x Type-C USB 3.2 Gen 1 5Gbps
• Form Factor
• Tower
• LED Indicators
• Status/Power, USB, LAN, Drive 1-6, M.2 SSD 1-2
• Buttons
• Power, Reset, USB Auto Copy
• Dimensions (HxWxD)
• 188.2 × 264.3 × 280.8 mm
• Weight (Net)
• 5.78 kg
• Weight (Gross)
• 7.35 kg
• Operating Temperature
• 0 - 40 °C (32°F - 104°F)
• Storage Temperature
• -20 - 70°C (-4°F - 158°F)
• Relative Humidity
• 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
• Power Supply Unit
• 250W, 100-240V AC, 50-60Hz, 3.5A
• Power Consumption: HDD Sleep Mode
• 21.891 W
• Power Consumption: Operating Mode, Typical
• 45.898 W
• Fan
• System fan: 2 x 92mm
• CPU fan: 1 x 60mm
• System Warning
• Buzzer
• Kensington Security Slot
• Yes
• Max. Number of Concurrent Connections (CIFS) - with Max. Memory
• 2000
