UBIQUITI UNIFI EXPRESS GATEWAY

• Mechanical

• Dimensions
• 98 x 98 x 30 mm
• Weight
• 302 g
• Enclosure material
• Polycarbonate

• Hardware

• Management interface
• Ethernet
• Bluetooth

• Networking interface

• LAN:
• (1) GbE RJ45 port
• WAN:
• (1) GbE RJ45 port
• Power method
• USB type C (5V DC/3A)
• Max. power consumption
• 10W
• Max. TX power
• 2.4 GHz: 22 dBm
• 5 GHz: 25 dBm
• MIMO
• 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
• 5 GHz: 2 x 2 (DL/UL MU-MIMO)
• Throughput rate
• 2.4 GHz: 573.5 Mbps
• 5 GHz: 2.4 Gbps
• Antenna gain
• 2.4 GHz: 4 dBi
• 5 GHz: 5.15 dBi
• Antennas
• (2) Internal 2.4G/5G WiFi dual-band antenna
• (1) Internal 2.4G single-band BT antenna
• LCM display
• 0.96" status display
• Button
• Factory reset
• Ambient operating temperature
• -10 to 45° C
• Ambient operating humidity
• 5 to 95% noncondensing
• Certifications
• CE, FCC, IC

• Gateway Features

• Performance
• Internet quality and outage reporting
• Next-generation security
• Application-aware firewall rules
• Content, country, domain, and ad filtering
• VLAN/subnet-based traffic segmentation
• Full stateful firewall
• Advanced networking
• License-free SD-WAN
• WireGuard, L2TP and OpenVPN server
• OpenVPN client
• OpenVPN and IPsec site-to-site VPN
• One-click Teleport VPN
• Policy-based WAN and VPN routing
• DHCP relay
• Customizable DHCP server
• IGMP proxy
• IPv6 ISP support

• Software

• WiFi standards
• 802.11a/b/g/n/ac/ax
• Wireless security
• WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
• BSSID
• Console mode: 3 per band
• Standard AP: 8 per band
• VLAN
• 802.1Q
• Advanced QoS
• Per-user rate limiting
• Guest traffic isolation
• Supported
• Concurrent clients
• 50+*
• *Performance may be degraded with advanced gateway features (e.g., Traffic Identification).

• Supported Data Rates

• 802.11a
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b
• 1, 2, 5.5, 11 Mbps
• 802.11g
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n (WiFi 4)
• 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
• 802.11ac (WiFi 5)
• 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
• 802.11ax (WiFi 6)
• 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)

• Application Requirements

• UniFi Network
• Version 8.0.7 and later
