TP-LINK VIGI C340S (4MM) IP KAMERA KÜLTÉRI SZÍNES ÉJJELLÁTÓ 4 MEGAPIXEL, 4MM OBJEKTÍV

• CAMERA

• Image Sensor
• 1/1.8" Progressive Scan CMOS
• Shutter Speed
• 1/3 to 1/10000 s
• Slow Shutter
• Yes
• Aperture
• 4 mm: F1.0
• Lens
• Fixed focal lens (4 mm)
• Lens Mount
• M12
• Minimum Illumination
• Color: 0.0005 Lux; 0 Lux with white light
• Day/Night Mechanism
• NA
• Day/Night Switch
• Day/Night/Auto/Schedule-Switch
• IR LED
• N/A
• White LED
• Quantity: 4
• Digital Noise Reduction
• 3D DNR
• WDR
• 120dB
• Weatherproof Rating
• IP67
• Illumination Distance
• 30 m
• Viewing Angle
• 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°

• LENS

• Type
• Fixed Focal Lens
• Focal Length
• 4 mm
• Aperture
• F1.0
• FOV
• 4mm: Horizontal FOV: 95.2°, Vertical FOV: 50.6°, Diagonal FOV: 114.7°
• Lens Mount
• M16*P 0.5
• DORI Distance
• 4 mm:
• Detect: 70 m (231 ft)
• Observe: 29 m (96 ft)
• Recognize: 14 m (46 ft)
• Identify: 7 m (23 ft)

• ANGLE ADJUSTMENT (MANUAL)

• Range
• Pan: -90° to 90°
• Tilt: -90° to 90°

• ILLUMINATOR

• IR LED
• N/A
• White LED
• Quantity: 4
• Range: 30m
• Illuminator On/Off Control
• Auto/Scheduled/Always on/Always off

• VIDEO

• Max. Resolution
• 2688 x 1520
• Main Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
• 2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
• Sub-Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution:
• 640x480, 352x288, 320x240
• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
• Bit Rate Control
• CBR, VBR
• Video Compression
• Main Stream: H.265+/H.265/H.264+/H.264
• Sub-Stream: H.265/H.264
• H.264 Type
• Main Profile/High Profile
• H.264+
• Main Stream Supported
• H.265 Type
• Main Profile
• H.265+
• Main Stream Supported
• Video Bit Rate
• Main Stream: 256 Kbps to 6 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps

• IMAGE

• Image Settings
• Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software, Rotation (90°/270°)
• Image Enhancement
• BLC/3D DNR/HLC
• Wide Dynamic Range
• 120 dB
• SNR
• > 52 dB
• Image Parameters Switch
• Yes
• Privacy Mask
• Up to 4 Masks
• ROI
• 1 Region
• OSD Setting
• Yes

• AUDIO

• Audio Communication
• Two-Way Audio
• Audio Input
• Yes
• Audio Output
• Yes
• Audio Compression
• Yes
• Audio Sampling Rate
• 8KHz
• Environment Noise Filtering
• Yes
• Audio Bit Rate
• 64 Kbps(G.711 alaw)

• NETWORK

• Protocol
• TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
• ONVIF
• Yes
• API
• ONVIF
• Simultaneous Live View
• 3 Main Streams & 3 Sub-Streams
• Client
• VIGI App, VIGI Security Manager, VIGI NVR, Web
• Web Browser
• Google Chrome© 57 and above
• Firefox© 52 and above
• Safari© 11 and above
• Microsoft© Edge 91 and above
• Cloud
• Yes
• Security
• Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
• Network Storage
• NAS (NFS, SMB/ CIFS)

• ALARM AND EVENT MANAGEMENT

• Smart Event
• Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection
• Basic Event
• Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
• Alarm Linkage
• Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
• Linkage Method
• N/A
• Output Notification
• Message Push

• DEEP LEARNING FUNCTION

• Multi-Target-Type Detection
• Supports Simultaneous Detection and Capture of Human Body and Vehicle
• People & Vehicle Analytics
• Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
• Face Capture
• Support
• Face Comparison
• Support
• Perimeter Protection
• Motion, Line-Crossing, Intrusion, Region Entering, Region Exiting, Loitering.
• Supports Alarm Triggering by Specified Target Types (Human and Vehicle)

• INTERFACES

• Network Interface
• 1 RJ45 10/100M Self-Adaptive Ethernet Port
• Audio Input
• Built-in Microphone
• Audio Output
• Built-in Speaker
• Alarm
• N/A
• Reset Button
• Yes
• Power
• DC Power Port
• Button
• Reset Button
• On-board Storage
• Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
• Built-in Microphone
• Yes; Records Anything Going on within a 15-ft Radius of the Camera
• Built-in Speaker
• Yes
• Audio
• N/A

• GENERAL

• Operating Temperature
• -30-60 °C
• Storage Temperature
• -40-60 °C
• Operating Humidity
• 95% or Less (Non-Condensing)
• Storage Humidity
• 95% or Less (Non-Condensing)
• Package Contents
• VIGI Network Camera
• Quick Start Guide
• Waterproof Cable Attachments
• Mounting Accessories
• Dimensions( H X W X D )
• 99 × 102 × 236 mm
• Materia
• Front Cover: Mental
• Other: Plastic
• Material
• Front Cover: Metal
• Back Cover: Plastic
• General Features
• Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
• Power Consumption
• 12V DC: Max 10.1W
• PoE: Class 0
• Power Supply
• 12V DC +/- 5%, 5.5mm Coaxial Power Plug
• PoE (802.3af/at, class 0)
• Protection
• IP67
• Product Dimensions (L x W x H)
• 102× 236× 99 mm
• Certifications
• CE, RCM, BSMI, VCCI, RoHS, NTRA, KC

• VIDEO/IMAGE

• Video Compression
• Main stream: H.265+/H.265/H.264+//H.264
• Sub-Stream: H.265/H.264
• Frame Rate & Resolutions
• Main Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution: 2688x1520,2560x1440, 2304x1296, 2048x1280, 1920x1080,1280x720
• Sub-Stream
• Frame Rate:
• 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
• 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
• Resolution: 640x480, 352x288, 320x240
• Video Streaming
• Main Stream
• Sub-Stream
• Image Settings
• Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
• Image Enhancement
• BLC, HLC, 3D DNR
• Video Bit Rate
• Main Stream: 256 Kbps to 4 Mbps
• Sub-Stream: 64 Kbps to 512 Kbps

• SMART FEATURE-SET

• Smart Event
• Intrusion Detection, Object Abandoned/Removal Detection, Region Entering Detection, Region Exiting Detection, Loitering Detection, Line Crossing Detection, Human Detection, Vehicle Detection
• Basic Event
• Motion detection, Camera Tampering, Scene Change Detection, Exception(illegal login)
• Linkage Method
• Trigger Notification: ONVIF, HTTPS
• Region of Interest
• 1 Region
