CYBERPOWER UPS, VP1200EILCD, 8X C13, 1200VA 720W 230V SZÜNETMENTES TÁPEGYSÉG + USB LINE-INTERACTIVE

• GENERAL

• Phase
• Single Phase
• Form Factor
• Tower
• UPS Topology
• Line-interactive
• Energy Saving Technology
• GreenPower UPS Bypass Technology

• INPUT

• Generator Compatibility
• Yes
• Nominal Input Voltage ( Vac )
• 230 +/- 10%
• Input Voltage Range ( Vac )
• 167 ~ 295
• Input Frequency ( Hz )
• 50 +/- 5
• 60 +/- 5
• Input Frequency Detection
• Auto-sensing
• Rated Input Current ( A )
• 5.2
• Input Connector Type
• IEC C14 ?

• OUTPUT

• Capacity (VA)
• 1200
• Capacity (Watts)
• 720
• On Battery Waveform
• Simulated Sine Wave
• On Battery Voltage(s) ( Vac )
• 230 +/- 10 %
• On Battery Frequency ( Hz )
• 50 +/- 1%
• 60 +/- 1%
• Automatic Voltage Regulation (AVR)
• Single Boost, Single Buck
• Overload Protection
• Circuit Breaker
• Outlet(s) - Total
• 8
• Outlet Type
• IEC C13 x 8 ?
• Outlet(s) - Battery & Surge Protected
• 4
• Outlet(s) - Surge-Only Protected
• 4
• Typical Transfer Time ( ms )
• 4

• BATTERY

• Runtime at Half Load ( min )
• 12
• Runtime at Full Load ( min )
• 4
• Typical Recharge Time ( Hours )
• 8
• Start On Battery
• Yes
• User-replaceable
• Yes - Qualified Personnel Only
• Battery Type
• Sealed Lead-acid

• SURGE PROTECTION & FILTERING

• Surge Suppression ( Joules )
• 450
• EMI/RFI Filtration
• Yes
• Phone/Network Protection RJ11/RJ45 (Combo)
• 1-in, 1-out

• MANAGEMENT & COMMUNICATIONS

• LCD Panel
• Yes
• LCD Information Display
• Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information
• LCD Setting & Control
• Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning
• LED Indicators
• Power On
• HID Compliant USB Port(s)
• 1
• Audible Alarms
• Battery Mode, Low Battery, Overload, UPS Fault
• Management Cable ( pcs )
• USB Cable x1
• Ethernet Data Transmission Speed
• Up to 1Gbps
• Power Management Software
• PowerPanel Personal (Recommended)

• PHYSICAL

• Enclosure Construction
• Plastic
• Color
• Black

• PHYSICAL SIZE - UPS MODULE

• Dimensions (WxHxD) (in.)
• 3.9 x 11 x 14
• Dimensions (WxHxD) (mm.)
• 100 x 281 x 355
• Weight (lbs.)
• 21.2
• Weight (kg.)
• 9.62

• SHIPPING DIMENSIONS

• Dimensions (WxHxD) (in.)
• 16.93 x 15.12 x 6.5
• Dimensions (WxHxD) (mm.)
• 430 x 384 x 165
• Weight (lbs.)
• 23.52
• Weight (kg.)
• 10.67

• ENVIRONMENTAL

• Operating Temperature (°C)
• 0 ~ 40
• Operating Relative Humidity (Non-condensing) ( % )
• 0 ~ 90
• Operating Elevation ( feet/meters )
• 0-9,843 feet (0-3,000 meters)
• Storage Temperature (°F)
• -4 ~ 122
• Storage Temperature (°C)
• -20 ~ 50
• Storage Relative Humidity (Non-condensing) ( % )
• 0 ~ 90
• Storage Elevation ( feet/meters )
• 0-9,843 feet (0-3,000 meters)
• Online Thermal Dissipation ( BTU/hr )
• 74
• Audible Noise at 1.0M from Surface of Unit ( dBA )
• 50

• CERTIFICATIONS

• Certifications
• CE, EAC
• RoHS
• Yes
